Automatic Folding Glass Doors

Automatic Folding Glass Doors
Automatic Folding Glass Doors
Product Code : 03
Product Description

Technical Specifications

Basic Data

Opening width (A)

800 - 2000 mm

Door leaf weight max

2 x 40 kg or 4x 40 kg

Door operating speed

0.7 m/s

Height of passage (G)

Up to 2500 mm

Operating housing D x H dimension

240 x 180 mm

Power supply

100-240 V AC, 50/60 Hz, 9OW

Ambient temperature

-15°C to +50°C

Trigger devices

Radar / infrared detectors, switch etc.

Basic Functions

Automatic Operation

On Way Traffic

Continuously Open

Manual Control

Interlock Function

Operating Lock

Automatic Reverse


Interlock Control

Emergency Cut-Off Function

Remote Control And Surveillance

Night Control

Bell Option

Door Leaf Surveillance

Key Operated Contact (SSK)

Module For Extended Functionality (FEM)

Assembly variants

Wall or beam assembly
